TL;DR: Metal stud partitioning offers straight, fire-resistant, and lightweight wall framing for offices, retail, and homes across Guildford. CSCS-accredited installation with 12-month guarantee.
Our Metal Stud Partitioning Service
Metal stud partitioning has become the preferred choice for modern construction and refurbishment projects. Unlike traditional timber framing, metal studs are straight, dimensionally stable, and resistant to warping, rot, and pests. At Drylining Guildford, we specialise in metal stud partition systems that deliver speed, strength, and flexibility for both commercial and residential clients.
- Metal C-stud and U-track framing systems
- Single and double-layer plasterboard cladding
- Acoustic insulation for sound-rated partitions
- Fire-rated partitions (30-120 minutes)
- Integrated door frames and glazing apertures
- Demountable and relocatable partition options
- Corner bead and trim finishing
- Professional taping and jointing for seamless surfaces
Why Choose Metal Stud Partitioning?
- Consistently straight and level walls: Metal studs do not warp, twist, or bow over time, ensuring your walls remain perfectly straight.
- Fire-resistant and non-combustible: Steel framing adds fire safety to your building and meets Part B regulations when combined with fire-rated boards.
- No warping, shrinking, or rot: Unlike timber, metal studs are unaffected by moisture, temperature changes, and pests.
- Lightweight and easy to handle: Metal studs are lighter than timber, making them faster to install and reducing structural load.
- Ideal for large-scale commercial fit-outs: Metal stud partitioning is the industry standard for office and retail developments due to its speed and reliability.
Materials & Specifications
We use industry-leading products from trusted manufacturers to ensure your metal stud partitions are strong, compliant, and built to last.
- Galvanised steel C-studs and U-tracks (50mm, 70mm, 92mm, and 146mm profiles)
- British Gypsum Gyproc plasterboard (standard, moisture-resistant, fire-rated, soundbloc)
- Knauf plasterboard and metal framing systems
- Rockwool and Isover acoustic insulation batts
- Fire-rated intumescent sealants and cavity barriers
- Steel corner beads and edge trim
- Joint compound and paper tape for seamless finishing
Applications & Use Cases
Metal stud partitioning is suitable for a wide range of building types and project sizes across Guildford.
- Office fit-outs and open-plan reconfigurations
- Retail store fitting and display wall construction
- Healthcare facility partition systems
- School and education building interiors
- Residential extensions and loft conversions
- Industrial unit and warehouse partitioning
- Hotels and hospitality refurbishment
How It Works
- Free Quote: Call or fill in our form. We will assess your layout, load-bearing requirements, and any acoustic or fire-rating needs.
- Detailed Plan: We confirm stud sizes, board types, insulation, and finishing specifications. Everything is agreed upfront with no hidden extras.
- Professional Installation: Our team installs the metal stud framework, fixes plasterboard to both sides, and completes joints with professional taping and finishing.
- Quality Check & Handover: We inspect every wall for straightness and finish quality, then leave your site clean and ready for decoration.
Metal Stud vs Timber Stud — What's Best for Your Project?
Both metal and timber studs create internal partition walls, but they behave very differently on site. The choice matters because it affects cost, build speed, fire rating, future modifications, and how easy it is to fix shelves or cabinets to the wall later. Here's how they compare for projects in the Guildford area.
| Attribute | Metal Stud (C-studs) | Timber Stud (CLS) |
|---|---|---|
| Cost (single-layer, supply + install) | £45 – £65/m² | £55 – £80/m² |
| Dimensional stability | Excellent — never warps, twists, or bows | Can warp, shrink, or bow over time |
| Fire performance | Non-combustible — adds to fire rating | Combustible — relies on plasterboard for fire rating |
| Moisture resistance | Unaffected by humidity and water | Can rot or develop mould if exposed to moisture |
| Pest resistance | Impervious to woodworm and termites | Susceptible to wood-boring insects |
| Fixing cabinets/heavy items | Needs plywood noggins or special fixings | Direct screw fixing into studs anywhere |
| Reconfigurable later | Easy — walls can be dismantled and rebuilt | Possible but slower |
| Best suited to | Offices, retail, modern homes, large fit-outs | Residential, period properties, low-rise |
For most Guildford office fit-outs, retail units, and modern residential extensions we recommend metal stud. For period properties in Burpham, Shalford, Ripley, and the conservation areas, timber stud often matches the existing construction and is easier to integrate with traditional lime plaster finishes. We install both — talk to us about which is right for your project.
Stud Profile Sizes & Applications
Metal stud is manufactured in four common widths. The right profile depends on the partition height, the acoustic and fire rating required, and whether the cavity is being used to run services (cables, pipework, insulation). The table below shows the standard sizes we use on Guildford projects.
| Stud Width | Typical Max Height | Best Application | Cavity Use |
|---|---|---|---|
| 50mm C-stud | 2.4 – 3.0m | Domestic partitions, store rooms, low-height offices | 25mm insulation only |
| 70mm C-stud | 3.0 – 3.6m | Standard office partitions, residential rooms | 25–50mm insulation + cables |
| 92mm C-stud | 3.6 – 4.5m | Commercial fit-outs, high ceilings, double-layer acoustic | 50mm insulation + services |
| 146mm C-stud | 4.5m+ | Cinemas, plant rooms, high-spec acoustic & fire walls | 100mm insulation + ductwork |
Studs are typically 0.5mm, 0.7mm, or 1.2mm gauge steel. Most Guildford projects use 0.55mm gauge for partitions up to 3m, upgrading to 0.7mm or 1.2mm for taller walls or higher fire ratings. We always specify the gauge and profile in writing as part of the quote.
Metal Stud Partition Costs in Guildford (2026)
Metal stud partition cost depends on the stud profile, board configuration, insulation, and any acoustic or fire rating required. The figures below are typical installed prices for projects in the Guildford area, including materials, labour, jointing, and waste removal. We provide a fixed written quote after a free site survey.
- Single-layer standard partition: £45 – £65/m². 50mm or 70mm C-stud, 12.5mm Gyproc plasterboard, no insulation. Suitable for storage and low-spec rooms.
- Single-layer sound-rated partition: £65 – £90/m². 70mm C-stud, 12.5mm SoundBloc board, 25mm Isover acoustic insulation. STC 38–42.
- Double-layer acoustic partition: £95 – £130/m². 92mm C-stud, 2×12.5mm SoundBloc each face, 50mm Rockwool RW3. STC 50–55. The standard for boardrooms.
- Fire-rated 60 minutes: £85 – £115/m². 70mm C-stud, 2×15mm British Gypsum FireLine, cavity barriers, intumescent sealant.
- Fire-rated 120 minutes: £135 – £180/m². 146mm C-stud, 2×19mm FireLine each face, 100mm Rockwool. Required for plant rooms and stairwells.
- Demountable office partitions: £110 – £260/m². Aluminium or steel track with glass or board panels; reconfigurable for changing layouts.
All prices exclude decorating (paint, wallpaper), electrics, and fire-rated doors. Final cost depends on layout complexity, access, and ceiling height. Request a free site survey for a fixed written quote.
Metal Stud Partitioning Across Guildford
We provide metal stud partitioning services in the following areas:
Related Services
Clients who book metal stud partitioning often also require:
Ready for a Free Metal Stud Quote?
Call us or fill in our quick form. We will arrange a site visit and provide a detailed, no-obligation quote.
Frequently Asked Questions about Metal Stud Partitioning
What is metal stud partitioning?
Metal stud partitioning is a modern wall framing system using lightweight steel studs and tracks. It creates strong, straight walls that are fire-resistant, dimensionally stable, and easy to modify in the future.
Is metal stud better than timber framing?
Metal studs offer several advantages over timber: they do not warp, rot, or shrink; they are fire-resistant; and they are lighter and easier to handle. They are the preferred choice for commercial and modern residential projects.
How long does metal stud partitioning take to install?
A typical office partition wall takes 1-2 days. Larger commercial fit-outs may take 3-7 days depending on the number of partitions and complexity of the layout.
Can metal stud walls be soundproofed?
Yes. We install acoustic insulation within the cavity and can use double-layer plasterboard with acoustic boards to achieve excellent sound reduction for offices, meeting rooms, and bedrooms.
Are metal stud partitions fire-rated?
Yes. When combined with fire-rated plasterboard, metal stud partitions can achieve fire ratings from 30 minutes up to 120 minutes, meeting building regulation requirements.
Can metal stud walls be moved or reconfigured later?
Yes. One of the key benefits of metal stud partitioning is that walls can be dismantled and reconfigured more easily than blockwork or traditional stud walls, making them ideal for flexible office layouts.
What areas do you cover for metal stud partitioning?
We provide metal stud partitioning across Guildford, Woking, Godalming, Farnham, Cranleigh, Epsom, Leatherhead, Burpham, Send, Merrow, Worplesdon, Shalford, Ripley, Betchworth, Stoughton, and all surrounding Surrey areas.
What size metal stud do I need?
The right metal stud size depends on partition height, acoustic and fire rating, and what is being run through the cavity. 50mm C-studs suit domestic partitions up to 2.4-3.0m with 25mm insulation only. 70mm C-studs are the standard for office partitions up to 3.0-3.6m, allowing 25-50mm insulation plus cables. 92mm C-studs handle commercial fit-outs up to 3.6-4.5m with 50mm insulation and services. 146mm C-studs are reserved for cinemas, plant rooms, and high-spec acoustic/fire walls over 4.5m.
What STC rating does a metal stud partition achieve?
A standard 70mm metal stud partition with single-layer 12.5mm Gyproc plasterboard achieves around STC 36-38. Adding 25mm Rockwool or Isover insulation lifts it to STC 40-44. Double-layer construction with 92mm studs, 2x12.5mm SoundBloc boards each side, and 50mm Rockwool RW3 reaches STC 50-55 — the standard for boardrooms and confidential meeting rooms. Staggered stud or double-stud walls with 100mm Rockwool achieve STC 60+, suitable for cinemas and high-spec acoustic requirements.
How much does metal stud partitioning cost per square metre in Guildford?
Metal stud partitioning in Guildford typically costs £45-£65/m² for single-layer standard, £65-£90/m² for single-layer sound-rated, £95-£130/m² for double-layer acoustic (boardroom grade), £85-£115/m² for 60-minute fire-rated, £135-£180/m² for 120-minute fire-rated, and £110-£260/m² for demountable office partitions. All prices include materials, labour, jointing, and waste removal; decorating and electrics are extra. We provide a free site survey and fixed written quote.
